| Description | 1000BASE-T SFP, 10/100/1000M | Auto-sense | MDI/MDIX |
| Max Data Rate | 1.25Gbps | support Hot-pluggable | Yes |
| Max Cable Distance | 100m | support Hot-pluggable | Yes |
| Connector | RJ45 | Warranty Time | 3 years |
Features:
• Up to 1.25Gb/s bi-directional data links
• Hot-pluggable SFP footprint
• Fully metallic enclosure for low EMI
• Low power dissipation
• Compact RJ-45 connector assembly
• Detailed product information in EEPROM
• +3.3V single power supply
• Access to physical layer IC via 2-wire
serial bus
• 10/100/1000 BASE-T operation in host
systems with SGMII interface
• Compliant with SFP MSA
• Compliant with IEEE Std 802.3TM-2002
• Compliant with FCC 47 CFR Part 15,
Class B
• RoHS Compliant Products
Applications:
• 1.25 Gigabit Ethernet over Cat 5 cable
• Switch/Router to Switch/Router Link
• High speed I/O for file severs
