| Max Data Rate | 25G | Warranty Time | 3 years |
| Max Cable Distance | 5m/OEM | DDM/DOM function | Yes |
| Connector | LC | power consumption | <1W |
| Wavelength | 850nm | Transmitter Type | VCSEL |
| Fiber Type（Media）: | OM3 | Receiver Type | PIN |
Product Features
• Supports 25Gbps data rate
• 850nm VCSEL laser and PIN photo-detector
• Electrical interface compliant to SFF-8431
• 850nm VCSEL laser and PIN photo-detector
• Maximum link length of 70m on OM3 MMF and 100m on OM4 MMF
• Digital diagnostics functions are available via the I2C interface
• Operating case temperature
• Commercial: 0°C to +70 °C
• +3.3V single power supply
• Power consumption less than 1W
• RoHS compliant
Application
• 25GBASE-SR Ethernet
• 32G Fiber Channel
