| Description | 400Gb/s QSFP56-DD | support Hot-pluggable | Yes |
| Max Data Rate | 400Gbps | Warranty Time | 3 years |
| Max Cable Distance | 70-100m | DDM/DOM function | Yes |
| Connector | MPO | No. of Fiber | 2 |
| Wavelength | 850nm | Fiber Type（Media）: | MMF |
Product Features
• Up to 53.125Gbps data rate per channel by
PAM4 modulation
• Support 400GAUI-8 electrical interface
• Integrated 850nm VCSEL array and PDarray
• Single MPO16 connector receptacle optical
interface compliant
• DDM function implemented
• Hot-pluggable QSFP-DD form factor
• Maximum power consumption 8W
• Single +3.3V power supply
• Reach up to 70m on MMF(OM3)
• Reach up to 100m on MMF(OM4)
• Compliant with ROHS2.0
Applications
•Data centers and Cloud
Networks
•400GE Interconnect
Requirements.
