| Description | 400G QSFP-DD FR4 | support Hot-pluggable | Yes |
| Max Data Rate | 425Gbps (4x 106.25Gbps) | Warranty Time | 3 years |
| Max Cable Distance | 2km | DDM/DOM function | Yes |
| Connector | LC | No. of Fiber | 2 |
| Wavelength | 1310nm | Fiber Type（Media）: | SMF |
Product Features
• Supports 400GBASE-FR4;
• Lane bit rate 106.25 Gb/s with PAM4;
• Up to 2km transmission on SMF;
• CWDM4 EML laser transmit and PIN receiver;
• 8x53.125Gb/s with PAM4 electrical interface (400GAUI-8);
• I2C interface with integrated Digital Diagnosticmonitoring;
• QSFP-DD MSA package with duplex LC connector;
• Single +3.3V power supply; • Maximum power consumption 12 W;
• Operating case temperature: 0 to +70 °C;
• Compliant to 802.3cu& QSFP-DD MSA HW standard;
• Complies with EU Directive 2015/863/EU;
Application
• 400GBASE-FR4;
• 400G Ethernet;
• Data center / Cloud application.
