| Description | 200Gb/s QSFP56 SR4 | support Hot-pluggable | Yes |
| Max Data Rate | 200Gbps | Warranty Time | 3 years |
| Max Cable Distance | 70-100m | DDM/DOM function | Yes |
| Connector | MPO | No. of Fiber | 2 |
| Wavelength | 850nm | Fiber Type（Media）: | MMF |
Product Features
• Compliant with 200G-SR4 opticalspecifications
• 4x53.125Gb/s electrical interface (200GAUI-4)
• Reach up to 70m on MMF(OM3)
• Reach up to 100m on MMF(OM4)
• Single +3.3V power supply
• Case temperature range: 0 ~+70℃
• Maximum power consumption 4W
• Single MPO12 connector
• RoHS complain
Applications
• 200G BASE-SR4 Ethernet links
•Data centers
Standards
•IEEE 802.3cd
•SFF 8679
•CMIS4.0 or SFF8636
