| Description | 10GBase-BIDI XFP+ | support Hot-pluggable | Yes |
| Max Data Rate | 10Gbps | Warranty Time | 3 years |
| Max Cable Distance | 80m | DDM/DOM function | Yes |
| Connector | LC | No. of Fiber | 1 |
| Wavelength | 1550/1490nm | Fiber Type（Media）: | SMF |
Product Features
• Supports 9.95Gb/s to 11.3Gb/s bit rates
• Hot-pluggable XFP footprint
• Up to 80km for SMF transmission
• XFI Loopback Mode
• 1490nm EML laser and APD receiver for UTX10Z8B45
• 1550nm EML laser and APD receiver for UTX10Z8B54
• Compliant with XFP MSA with single LC receptacle
• Compatible with RoHS
• Single +3.3V power supply
• Power dissipation<2.5W
• 2-wire interface with integrated Digital Diagnostic monitoring
• EEPROM with Serial ID Functionality
• Operating case temperature:
• Standard: -5 to +70°C
• Industrial: -40 to +85°C
Applications
• 10GBASE-BX 10.3125Gb/s Ethernet
• 10GBASE-BX 9.953Gb/s Ethernet
• SONET OC-192 SR-1 SDH STM I-64.1
