| Description | 10G SR SFP+ | support Hot-pluggable | Yes |
| Max Data Rate | 10Gbps | Warranty Time | 3 years |
| Max Cable Distance | 300km | DDM/DOM function | Yes |
| Connector | LC | No. of Fiber | 2 |
| Wavelength | 850nm | Fiber Type（Media）: | MMF |
Product Features
• Electrical interface compliant to SFF-8431
• Lane bit rate 10.3 Gb/s
• 850nm VCSEL laser and PIN photo-detector
• I2C interface with integrated Digital Diagnostic monitoring
• Single +3.3V power supply
• Hot Pluggable
• Maximum link length of 300m on OM3 MMF
• Operating case temperature
Commercial: 0°C to +70 °C
Industrial: -40°C to +85 °C
• RoHS compliant
Application
• 10 Gigabit Ethernet
• 1ⅹInfiniBand QDR, DDR, SDR
• High-performance computing clusters
• 4G and 8G Fiber Channel Applications
• Servers, switches, storage and host card adapters;
