| Description | 10GBase-BIDI SFP+ | support Hot-pluggable | Yes |
| Max Data Rate | 10Gbps | Warranty Time | 3 years |
| Max Cable Distance | 80km | DDM/DOM function | Yes |
| Connector | LC | No. of Fiber | 1 |
| Wavelength | 1490/1550nm | Fiber Type（Media）: | SMF |
Product Features
• Supports 11.1Gb/s bit rates
• Hot-pluggable SFP+ footprint
• Up to 80km for SMF transmission
• 1490nm EML laser and APD receiver for UTS10Z8B45
1550nm EML laser and APD receiver for UTS10Z8B54
• Compliant with SFP+ MSA with single LC receptacle
• Compatible with RoHS
• Single +3.3V power supply
• Power dissipation<1.8W
• 2-wire interface with integrated Digital Diagnostic monitoring
• EEPROM with Serial ID Functionality
• Operating case temperature:
Standard: -5 to +70°C
Industrial: -40 to +85°C
Applications
• 10GBASE-BX 10.3125Gb/s Ethernet
