| Description | 1.25G CWDM SFP | support Hot-pluggable | Yes |
| Max Data Rate | 1.25Gbps | Warranty Time | 3 years |
| Max Cable Distance | 120km | DDM/DOM function | Yes |
| Connector | LC | No. of Fiber | 2 |
| Wavelength | 1470~1610nm | Fiber Type（Media）: | SMF |
Product Features
• Up to 1.25Gbps Data Links
• DFB laser transmitter and APDreceiver
• Metal enclosure, for lower EMI
• Single +3.3V power supply
• Hot-pluggable
• Duplex LC/UPC type pluggable optical interface
• Operating temperature range:
Commercial: -5℃~+70℃
• RoHS Compliant
• 2-wire interface with integrated Digital Diagnostic monitoring
• Up to 120km transmission distance over Single ModeFiber(SMF)
• Low power dissipation
Application
• Switch to Switch Interface
• Gigabit Ethernet
• Switched Backplane Applications
• Router/Server Interface
• Other Optical Links
