| Description | 1.25G DWDM SFP | support Hot-pluggable | Yes |
| Max Data Rate | 1.25Gbps | Warranty Time | 3 years |
| Max Cable Distance | 80km | DDM/DOM function | Yes |
| Connector | LC | No. of Fiber | 2 |
| Wavelength | C-Band | Fiber Type（Media）: | SMF |
Product Features
• Up to 1.25Gbps Data Links
• Transceiver unit with independent DWDM DFBLaser diode transmitter PIN photodiode receiver
• Metal enclosure, for lower EMI
• Single +3.3V power supply
• 100GHz ITU Grid, C Band
• Duplex LC/UPC type pluggable optical interface
• Operating temperature range:
Commercial: -5℃~+70℃
• RoHS Compliant
• Wavelength controlled within ± 0.1nm over life and temperature
• Digital diagnostic monitoring
• 80 km with 9/125 µm single mode fiber (SMF) of maximum interconnect distances
• Low power dissipation
Application
• C Band DWDM networks
• SONET/SDH networks
• Fiber channel
• Gigabit Ethernet
