| Description | 10GBase-CWDM SFP+ | support Hot-pluggable | Yes |
| Max Data Rate | 10Gbps | Warranty Time | 3 years |
| Max Cable Distance | 60km | DDM/DOM function | Yes |
| Connector | LC | No. of Fiber | 2 |
| Wavelength | 1270~1450nm CWDM | Fiber Type（Media）: | SMF |
Product Features
• Up to 11.1Gbps Data Links
• CWDM EML transmitter and APD receiver
• Metal enclosure, for lower EMI
• Single +3.3V power supply
• Hot-pluggable
• Without CDR or with CDR supported 9.95 to 11.3Gb/s reference-free
• Operating temperature range: Commercial: -5℃~+70℃
• RoHS Compliant
• 2-wire interface with integrated Digital Diagnostic monitoring
• Up to 60km transmission distance over Single Mode Fiber(SMF)
• Low power dissipation
Without CDR:1.4W power dissipation without CDR for Commercial temperature
With CDR:1.5W power dissipation with CDR for Commercial temperature
Applications
• 10GBASE-BX
• 10G SONET/SDH, OTU2/2e
